            Arduino Basic Elevator Simulation

  		  www.ulasdikme.com

     **********************************************************
   */


  int i=1; // the value represents where elevator stay ( fisrt time elevator start in the first floor
  int btn4=8; // represents the 4 th floor
  int btn3=7;  //             2 nd floor
  int btn2=6; //                3 th floor
  int btn1=5;  //               1 st floor

  int buttonState=0;
  int buttonState2=0;
  int buttonState3=0;
  int buttonState4=0;


  int motorPin1 = 10;
  int motorPin2 = 11;
  int motorPin3 = 12;
  int motorPin4 = 13;

  const int latchPin = 3;  // Pin connected to Pin 12 of 74HC595 (Latch)
  const int dataPin  = 4;  // Pin connected to Pin 14 of 74HC595 (Data)
  const int clockPin = 2;  // Pin connected to Pin 11 of 74HC595 (Clock)

  const byte numbers[16] = {
    0b11111100,
    0b01100000,
    0b11011010,
    0b11110010,
    0b01100110,
    0b10110110,
    0b10111110,
    0b11100000,
    0b11111110,
    0b11100110,
    0b11101110,
    0b00111110,
    0b10011100,
    0b01111010,
    0b10011110,
    0b10001110
  };

  void setup() {

    pinMode(latchPin, OUTPUT);
    pinMode(clockPin, OUTPUT);
    pinMode(dataPin, OUTPUT);


   pinMode(motorPin1, OUTPUT);
   pinMode(motorPin2, OUTPUT);
   pinMode(motorPin3, OUTPUT);
   pinMode(motorPin4, OUTPUT);
    int delayTime = 50;


    Serial.begin(9600);

    pinMode(btn4,INPUT);
    pinMode(btn2,INPUT);
    pinMode(btn3,INPUT);
    pinMode(btn1,INPUT);


  }

  void loop() {
   // Serial.println("You are on the i st floor");
  buttonState = digitalRead(btn1);
  buttonState2 = digitalRead(btn2);
  buttonState3 = digitalRead(btn3);
  buttonState4 = digitalRead(btn4);
  show(numbers[i]); //write number on the 7 segment display  which floor elevator stays

  /*------------------------------------------------------------------*/
  // 4 th floor required codes
  if(buttonState4 == HIGH){
  while(i<4){
      i++;
          up();

   Serial.print("You are on the ");
      Serial.print(i);
      Serial.println("floor");
     show(numbers[i]);

    }
    i=4;
    show(numbers[i]);

    }// end of the buttonState4
  //------ end of the 4th floor ------
  /*------------------------------------------------------------------*/


  /*------------------------------------------------------------------*/
   //start of the 3 td floor codes ----
    if(buttonState3==HIGH){

      if(i>3){
        while(i>3) {
        i--;
        down();
      Serial.print("You are on the ");
      Serial.print(i);
      Serial.println("floor");
     show(numbers[i]);
        }
      }
      if(i<3){ // person is waiting on the first or second floor. Call the elevater
        while(i<3){
          i++;
          up();
     Serial.print("You are on the ");
      Serial.print(i);
      Serial.println("floor");
      show(numbers[i]);
      }

      }


    i=3; //assign the elevator value to the three
     show(numbers[i]);
        delay(1000);



    } // end of the buttonState3
    //end of the 3 td floor codes ----
   /*------------------------------------------------------------------*/





   /*------------------------------------------------------------------*/
  // 2 nd floor required codes
    if(buttonState2 == HIGH){
    if(i>2){
      while(i>2)
      {
      i--;
      down();
      Serial.print("You are on the ");
      Serial.print(i);
      Serial.println("floor");
  	show(numbers[i]);
      }
      i=2;
  	}
        if(i<2){
        while(i<2){
          i++;
          up();
      Serial.print("You are on the ");
      Serial.print(i);
      Serial.println("floor");
  	show(numbers[i]);

        }
        i=2;
  	  show(numbers[i]);
        delay(1000);
      }

      }// end of the buttonState2
  // --- end of the 2 th floor codes ---
  /*------------------------------------------------------------------*/



  /*------------------------------------------------------------------*/
  // start of the 1 st floor codes ------
    if(buttonState == HIGH){
      if(i>1){
        while(i>1){

        i--;
        down();
      Serial.print("You are on the ");
      Serial.print(i);
      Serial.println("floor");
  	show(numbers[i]);

      }
      }
      i=1;
  	show(numbers[i]);
      delay(1000);
    }// end of the buttonState1
    //--- end of the first floor codes-----
    /*------------------------------------------------------------------*/



  }




  // ------- up function which is for to go up elevator
  void up() { // each floor distance where it works to up

    for(int b=0; b<300; b++){
    show(numbers[i]);
    digitalWrite(motorPin1, LOW);
    digitalWrite(motorPin2, LOW);
    digitalWrite(motorPin3, LOW);
    digitalWrite(motorPin4, HIGH);
    delay(3);
    digitalWrite(motorPin1, LOW);
    digitalWrite(motorPin2, LOW);
    digitalWrite(motorPin3, HIGH);
    digitalWrite(motorPin4, LOW);
    delay(3);
    digitalWrite(motorPin1, LOW);
    digitalWrite(motorPin2, HIGH);
    digitalWrite(motorPin3, LOW);
    digitalWrite(motorPin4, LOW);
    delay(3);
    digitalWrite(motorPin1, HIGH);
    digitalWrite(motorPin2, LOW);
    digitalWrite(motorPin3, LOW);
    digitalWrite(motorPin4, LOW);
    delay(3);
    }

  }

  void down() { // each floor distance where it works to down


   for(int a=0;a<300;a++){
    show(numbers[i]);
   digitalWrite(motorPin1, HIGH);
   digitalWrite(motorPin2, LOW);
   digitalWrite(motorPin3, LOW);
   digitalWrite(motorPin4, LOW);
   delay(3);
   digitalWrite(motorPin1, LOW);
   digitalWrite(motorPin2, HIGH);
   digitalWrite(motorPin3, LOW);
   digitalWrite(motorPin4, LOW);
   delay(3);
   digitalWrite(motorPin1, LOW);
   digitalWrite(motorPin2, LOW);
   digitalWrite(motorPin3, HIGH);
   digitalWrite(motorPin4, LOW);
   delay(3);
   digitalWrite(motorPin1, LOW);
   digitalWrite(motorPin2, LOW);
   digitalWrite(motorPin3, LOW);
   digitalWrite(motorPin4, HIGH);
   delay(3);

   }
  }

  void show( byte number)
  {
    // Use a loop and a bitwise AND to move over each bit that makes up
    // the seven segment display (from left to right, A => G), and check
    // to see if it should be on or not
    for(int j = 0; j <= 7; j++)
    {
      byte toWrite = number & (0b10000000 >> j);

      // If all bits are 0 then no point writing it to the shift register,
      // so break out and move on to next segment.
      if(!toWrite) {
        continue;
      }

      // Otherwise shift it into the register
      shiftIt(toWrite);
    }
  }

  void shiftIt (byte data)
  {
    // Set latchPin LOW while clocking these 8 bits in to the register
    digitalWrite(latchPin, LOW);

    for (int k=0; k <= 7; k++)
    {

      // clockPin LOW prior to sending a bit
      digitalWrite(clockPin, LOW);

      // Note that in our case, we need to set pinState to 0 (LOW) for
      // “On” as the 74HC595 is sinking current when using a common
      // anode display. If you want to use a common cathode display then
      // switch this around.
      if ( data & (1 << k) )
      {
        digitalWrite(dataPin, LOW); // turn “On”
      }
      else
      {
        digitalWrite(dataPin, HIGH); // turn “Off”
      }

      // and clock the bit in
      digitalWrite(clockPin, HIGH);
    }

    //stop shifting out data
    digitalWrite(clockPin, LOW);

    //set latchPin to high to lock and send data
    digitalWrite(latchPin, HIGH);

    // put delay here if you want to see the multiplexing in action!
    //delay(100);
  }
